Pulsar Turbo PSR3584 GEN3 Billet Compressor WheelDual Ball Bearing Turbocharger Dual Vband Inlet&Outlet 0.83 A/R
-Application:Fit Vehicle: Universal turbo for performance use, racing car, etc.Fit engine displacement 2.0-5.5L.
-Features:10 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip TechnologyInconel 713c 10 Blade Turbine Wheel with High HorsepowerCover Integrated with the Speed Sensor PortMax Air Flow rate: ~90 lb/min, rated @ 1000 FWHPLarger Turbine Wheel for Higher flowPSR3584 GEN3 TURBO comes with Larger Turbine Wheel for higher flow.It has been tested and gets more than nearly 50 hp!
-Item Details:Dual Ceramic ball bearing;Billet Compressor Wheel: 67/84mm, 10+0 Blades;Compressor Housing: 4'' inlet, 2.5'' outlet, 0.72 A/R, Anti-surge;Larger Turbine Wheel: 74/66mm;Turbine Housing:Dual Vband, 0.83A/R;Turbine housing Inletflange&clamp fit: 2.5'' OD tubing, slip on & weld.Turbine housing Outletflange&clamp fit: 3'' OD tubing, slip on & weld.Oil Feed: -4 AN connect to the Oil RestrictorOil Drain: Std T3 FlangeWater In/Outlet: M14*1.5We highly recommend running water cooling for better durability.
-Package list:Complete Turbocharger*1Inlet Flange Kit*1Outlet Flange Kit*1Oil Restrictor*1Water Fittings*2Oil Drain Flange Kit with -10AN Thread*1
This listing comes with A Dual Vband 0.83 A/R turbine housing by default. Make sure to let me know if you need other turbine housing.
-Other Pulsar Turbo PSR3584GEN3Options,Please Click on the link in the form.
NO.
Turbine housingOptions
NO.
Turbine housingOptions
1
T3 Open Inlet, V-band Outlet 0.63 A/R
10
Super Core
2
T3 Open Inlet, V-band Outlet 0.82 A/R
11
Stainless Steel Dual V-band 0.82 A/R
3
T3 Open Inlet, V-band Outlet 1.06 A/R
12
Stainless Steel Dual V-band 0.82 A/R+T25 Adapter
4
T4Open Inlet, V-band Outlet 0.82 A/R
13
Stainless Steel Dual V-band 0.82 A/R+T3 Adapter
5
T4 Divided Inlet, V-band Outlet 0.85 A/R
14
Stainless Steel Dual V-band 0.82 A/R+T4 Adapter
6
Dual V-band 1.01 A/R
15
Stainless Steel Dual V-band 1.03 A/R
7
Dual V-band 1.01 A/R+T4 Adapter
16
Stainless Steel Dual V-band1.03 A/R+T25 Adapter
8
Dual V-band 0.83 A/R
17
Stainless Steel Dual V-band 1.03 A/R+T3 Adapter
9
Dual V-band 0.83 A/R+T4 Adapter
18
Stainless Steel Dual V-band 1.03 A/R+T4 Adapter
-Special Note:1. Professional install is highly recommended!Please ask all questions prior to We default accept PayPal. Please send message to us if you would like to other methods.All major credit cards are accepted through secure payment processor PayPal.2. We usually keep the unpaid item only for 7 days. If you don't want to buy it after you have placed an order, please also let us know. We could come to an agreement to cancel this transaction so that we’ll resolve this problem properly with both have no loss. Or please DO make your payment through PayPal as quickly as possible.
Shipping:1. Once your payment is verified, your items will be shipped within 24-72 hours. No shipment on Weekends.2. We ship to your address. Please make sure your address is correct before you pay.3. You can choose faster shipping method, if the carrier can’t ship finally, we will cancel the order, or ship it via normal shipping method and refund the extra shipping cost.4.Item(s) might be sent out in multiple packages from our overseas warehouse via UPS, DHL, FedEx, etc. at our discretion, you are responsible for the import duty (If Any) upon delivery.
Warranty:1. Return:Pulsar Turbo System provides 30 days money back or item exchange (buyer's choice), but the buyers pay the return shipping. The item must be returned in the original packaging and in original condition in order to qualify for the exchange. offerding is a legal contract and you agreed to this when you registered with . Please don’t refuse shipment without communication.
2. Damaged Shipments:Please file a claim with the shipping company if goods arrive in a damaged condition. At the same time, also please notify Pulsar Turbo System with pertinent information.
3. Shortage or Discrepancy ClaimShortage or Discrepancy Claim must be reported within forty-eight (48) hours of receipt of goods.Pulsar Turbo System will either issue a credit or send a replacement(s) at no charge. Please send message to us for instructions on how to address shortages or discrepancies.
4. Limited WarrantyWe offer a 1-year manufacturer warranty from the date of purchase against all our products for defects in materials and workmanship. If an approved warranty claim is made, we will, at our sole discretion, either credit the original purchaser with an amount equal to the original purchase price or replace the applicable Turbocharger Product free of charge within 30 days of approval. This is the purchaser’s sole and exclusive remedy and provides complete financial responsibility for a warranty claim.Please note individual components, rebuild kits, and upgrade kits are not covered by the warranty ONCE INSTALLED. This is due to our inability to determine the pre-existing condition of the turbocharger before the rebuild or installation process, as well as our inability to guarantee proper re-balancing and assembly of the turbochargers.
