The AUTMATCH Upgrade Trailer Hitch Ball Mount Set Provides Superior Towing Power And Each Set Also Comes With A Anti-Theft Trailer Hitch Lock Pin and Hitch Tightener Anti-Rattle Clam For Mounting The Ball Mount Into The 2Inch Size Receiver Tube, For Meet Your Towing Power of More Security And Stability Needs and Escort For Your Travels. Our Vision Was To Create An Brave Exploration Brand That Aligns With Our Core Beliefs, A Brand You Will Resonate With and Eagerly Join In, Changing The World Around Us By Helping Support A Great Cause.
GO ANYWHERE & DO ANYTHINGHow To Choose Trailer Hitch Ball Mount?
Q:How Much Weight You Are Going To Be Towing?
A:Should Never Exceed The Weight Capacity Of Any Component Of Your Vehicle, Trailer Or Trailer Hitch Setup.
Q: What Size Receiver Tube Of Your Trailer Hitch?
A: Receiver Tubes Come In A Handful Of Standard Sizes, Including 1-1/4, 2, 2-1/2 And Sometimes 3 Inches, So Finding A Ball Mount To Match Is Relatively Easy.
Q: How Much Drop Or Rise Your Ball Mount Will Need?
A: This Hitch Is Rated To Be Flipped Over To Give 3/4\" Rise As Well As The 2\" Drop
TRAILER HITCH BALL MOUNT SPECIFICATIONS:A dependable connection to your off-road lifestyle
Top Material:Ultra-Strong Drop Forged Steel
Working Load Limit:3.6T (8,000 Lbs GTW Capacity) and 800 Lbs TW Capacity
Breaking Strength Limit:8.5 Ton (18,700 Lbs Capacity)
Craft:High-Strength Drop Forging + Polished Chrome Plating Ball + Zinc-Galvanized & Powder Coated
FOR SAFE USE OF TRAILER HITCH BALL MOUNT, PLEASE CONSIDER THE FOLLOWING:
- Adjust Installation of Trailer Hitch Ball Mount By Adding or Removing Silicone O-Rings on Your Hitch Lock Pin
- Anti-Theft Trailer Hitch Lock Pin By Using the Push-To-Lock Mechanism + Extra Safety Spring Clip
- Anti-Rattle Hitch Tightener Ensures Eliminate of Wobble, Rattle & Noise, Provide a Quiet and Stable Towing & Hauling Experience
- Use Washer on the Bottom of Ball Mount Protects Equipment Paint Surface, To Meet Your Towing Power of More Security and Stability Needs
PACKAGE INCLUDES:
- 1Pc 2\" Trailer Hitch Ball Mount
- 1Pc 2\" Inch Tow Ball & Rubber Washer
- 1Pc 2\" Hitch Tightener Anti-Rattle Clamp
- 1Pc 5/8\" Trailer Hitch Lock Pin with Extra Safety Spring Clip & 2 Spare Keys
- Zinc-Galvanized & Chrome Plating & Powder Coated
- Perfect For Towing Trailer, Tow Boat, Campers, Hauling Motorcycles and ATV & UTV With 2 Inch Standard Hitch Receiver
AUTMATCH TRAILER HITCH BALL MOUNT KIT FEATURES:Heavy-Duty TRAILER HITCH BALL MOUNT
*Trailer Hitch Mount With Ball Provides Reliability For Your Towing Setup: 2-Inch Trailer Hitch Ball - GTW: 8,000Lbs with TW: 800Lbs
*Construct Of Ultra-Strong Drop Forged Steel, Protected With By Polished Chrome Plating, Galvanized & Powder Coated Finish
*Easy To Be Installed And Insert The Shank Into 2\" Hitch Receiver And Then Connect The Two Vehicles With The Trailer Ball
*This Hitch Is Rated To Be Flipped Over To Give 3/4\" Rise Or The 2\" Drop To Level Trailer Line
HOW TO USE THE HITCH TIGHTENER
1.Drop The U-Bolt and Slide It To Touch The Face of Hitch.
2.Push The Tightener Plate Onto U-Bolt With Raised End Away From The Hitch Receiver
3.Have The Washer, Lock Washer and Nut To One Side of The U-Bolt. Hand Tighten Nut To Hold Washers In Place.
4.Tighten The Nuts Evenly Until Metal Plate Is Tight To The Stinger And Hitch. Check The Nuts Periodically To Ensure That They Remain Tight.
ANTI-THEFT PUSH-TO-LOCK DESIGN
*1/4 Turn Lock and Push To Lock Design, Easy To Operate.
*2 Unique Tubular Keys Improve The Security and Anti-Theft Function Of The Lock
*Watertight Dust Rubber Cap Prevents Locking Mechanism Internal Corrosion.
*Each Lock Is Keyed Unique and Please Keep it Well
*AUTMATCH Motto: Go Anywhere & Do Anything!
HOW TO DETERMINE DROP OR RISE?
After You Know How Much Weight You Will Be Towing And The Size Of Your Receiver Tube, You Will Need To Determine The Drop Or Rise Necessary For Your Trailer.
Drop Or Rise Is The Amount Of Height Difference Between The Trailer And Your Tow Vehicle, Whether That Difference Is Positive (Rise) Or Negative (Drop).
The Diagram Offers A Quick Explanation For How To Determine Your Needed Drop Or Rise. Take The Distance From The Ground To The Top Of The Inside Of Your Receiver Tube Opening (A), And Subtract It From The Distance From The Ground To The Bottom Of The Trailer Coupler (B).
A Minus B Equals C / The Drop Or Rise.
