Offered by The Faithful Aviators Treasure Hunter Store, this is an original vintage 1958 U.S. military aircraft technical manual for the Beech T-34A and Navy T-34B aircraft.
The manual is identified as:
T.O. 1T-34A-4
NAVAER 01-90KDB-504
Illustrated Parts Breakdown
USAF Series T-34A
Navy Model T-34B Aircraft
Revised January 25, 1958
This historical aviation publication contains detailed aircraft parts breakdowns, group assembly parts lists, exploded-view illustrations, component diagrams, aircraft installation drawings, part numbers, hardware listings, maintenance references, and assembly identification information.
Photographed sections include technical illustrations for:
Right-hand wing electrical installation
T-34B wing fuel cell installation
Vertical stabilizer assembly
Aircraft structural components
Fuel cell assemblies and filler-cap components
Stabilizer, rudder, hinge, bushing, bearing, and actuator assemblies
Aircraft electrical and mechanical installation details
Illustrated parts index and effective-pages information
The parts listings include vintage military aircraft component terminology such as cell installation, wing fuel LH and RH, adapter assembly, fuel filler cap, gasket, fuel cell access cover, spacer, stabilizer assembly, rudder hinge assembly, half-hinge, wear bushing, bearing, and actuator installation.
This manual is a desirable collectible for:
T-34 aircraft enthusiasts
Beechcraft collectors
U.S. Air Force memorabilia collectors
U.S. Navy aviation historians
Military technical manual collectors
Vintage aircraft restoration research
Aviation museums and displays
Aircraft maintenance history researchers
Cold War-era aviation collections
Period military documentation collections
The manual is being sold as a vintage historical reference and collectible publication. It is not being represented as a current maintenance or airworthiness document. Always consult current, approved technical data before performing any aircraft inspection, repair, restoration, or maintenance work.
Please examine the photographs closely. The actual item pictured is the item you will receive.
Item Specifics
Specific Details
Brand Beech Aircraft / U.S. Military
Type Illustrated Parts Breakdown Manual
Aircraft Beech T-34A and Navy T-34B
Publication Number T.O. 1T-34A-4
Navy Reference NAVAER 01-90KDB-504
Branch U.S. Air Force / U.S. Navy
Model T-34A / T-34B
Publication Era 1950s
Revision Date January 25, 1958
Language English
Subject Aircraft Parts, Maintenance, Assemblies
Format Printed Technical Manual
Original/Reproduction Original vintage publication
Country/Region of Manufacture United States
Binding Binder-style technical manual; verify exact configuration from photographs
Modification Description None known
Vintage Yes
Handmade No
Personalization None
Signed No
Unit of Sale Single manual
Intended Use Reference, collecting, display, research
Condition Used; aged vintage condition
